| Item name | EXSU-102RC | EXSU-103RC | EXSU-202RC | EXSU-203RC |
|---|---|---|---|---|
| Length m | 10 | 10 | 20 | 20 |
| Inner diameter×Outer diameter mm | 6.5×10 | 8.5×12.5 | 6.5×10 | 8.5×12.5 |
| Standard pressure Mpa | 1.5 (at 20°C) | 1.5 (at 20°C) | 1.5 (at 20°C) | 1.5 (at 20°C) |
| Use temperature range ℃ | -20～60 | -20～60 | -20～60 | -20～60 |
| Allowable bending radius mm | 40 | 55 | 40 | 55 |
| Mass kg | 0.8 | 1.1 | 1.4 | 1.9 |
