| Electric motor rated output kW｛PS｝ | 7.5｛10｝ |
|---|---|
| Control pressure MPa（kgf/cm2） | 0.7-0.85 |
| Output air volume L/min | 825 |
| Air tank capacity L | 70 |
| Air outtake B | Rc3/4×1 |
| Dryer pressure dewpoint (℃) |
15 or lower |
| Dryer Refrigerant | HFC134a |
| External dimensions (W x D x H)mm | 1230×870×1480 |
| Mass kg | 356 |
| Noise level (1.5m in front) dB(A) | 56 |
| Operating control method | Pressure switch |
| Voltage V | Three-phase 200 |
