| Electric motor rated output kW｛PS｝ | 3.7 |
|---|---|
| Control system | Automatic start and stop［Pressure sensor detection］ |
| Control pressure MPa（kgf/cm2） | 0.65-0.8 |
| Output air volume L/min | 410 |
| Air tank capacity L | 35 |
| Air outtake B | Rc3/8 |
| Dryer pressure dewpoint (℃) |
15 or lower |
| Dryer Refrigerant | HFC134a |
| External dimensions(W x D x H)mm | 545×622×1058 |
| Mass kg | 140 |
| Noise level (1.5m in front) dB(A) | 49 |
| Voltage V | Three-phase200 |
