| Electric motor rated output kW｛PS｝ | 5.5｛7.5｝ |
|---|---|
| Control pressure MPa（kgf/cm2） | 0.8-1.0 |
| Output air volume L/min | 580 |
| Air tank capacity L | 155 |
| Air outtake B | Rc3/4×1 G1/4×1 plug |
| External dimensions (W x D x H)mm | 1335×575×1080 |
| Mass kg | 200 |
| Noise level (1.5m in front) dB(A) | 75 |
| Operating control method | Pressure switch |
| Voltage V | Three-phase 200V |
