| Format | LPH-50-042G | LPH-50-062G | LPH-50-102G |
|---|---|---|---|
| Paint feeding system | Gravity type | ||
| Paint nozzle aperture φmm | 0.4 | 0.6 | 1 |
| Spray air pressure MPa | 0.09 | ||
| Pressure inside cap MPa | 0.07 | ||
| Air volume usage l/min | 50 | ||
| Paint spray volume ml/min | 8 | 25 | 55 |
| Pattern openness mm | 40 | 60 | 100 |
| Advanced finishing | ● | ||
| Applied air cap format | E2 | ||
| Required compressor kW | 0.2-0.75 | ||
| Massg | 220 | ||
| Uses | For car repair (touch up and gradation painting) | ||
